Top mount diffuser 6” flange
[返回]
详细信息
| Serial No. | Item No. | SIZE (mm) | Diameter(inches/mm) | Slot Size | Top opening | |||
| A | B | C | D | |||||
| JD415 | SS-7-250F | 260 | 340 | 140 | Φ90(Φ89) | 40"~48" (Φ1000~Φ1200mm) | 0.25~0.3mm | 6"FLG |
| JD416 | SS-7-300F | 310 | 390 | 140 | Φ90(Φ89) | 48"~64" (Φ1200~Φ1600mm) | 0.25~0.3mm | 6"FLG |
| JD417 | SS-7-400F | 410 |
440 |
140 | Φ90(Φ89) | 64"~80" (Φ1600~Φ2000mm) | 0.25~0.3mm | 6"FLG |
